ABB M2BAX 90SLA4

Series: M2BAX

Source: https://storage.googleapis.com/dxwdqishdsagre/abb-switchgear

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the M2BAX 90SLA4, ABB offers a three-phase induction motor in the M2BAX series. The rated output is 1.5 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The rated voltage is 415 V. The housing is frame size 90. The protection class is IP55, IP56, IP65 and IP66. The efficiency is 85.3 per cent at full load, 84.8 per cent at 75 per cent load and 82.9 per cent at half load. The motor is built in India. The values are recorded in the Australian MEPS registration under the GEMS Determination 2019; measured to IEC 60034-2-1 (Edition 2.0). The M2BAX series covers 61 models. Rated output within it ranges from 0.75 to 184.99 kW; the M2BAX 90SLA4 sits at the bottom of that range with 1.5 kW. Its immediate neighbours are the M2BAX 90SB 4 below it with 1.1 kW and the M2BAX 100 LB 4 above it with 2.2 kW. 2141 ABB models across 12 series are on record.

ABB M2BAX – three-phase motor range, per manufacturer logic the predecessor generation to the M3 range, manufactured in Finland, Poland, China and India, frame sizes 80 to 355, 0.75 to 185 kW

This page gathers the M2BAX range motors from ABB as listed in the Australian energy-efficiency register. M2BAX belongs, per manufacturer logic, to the older generation of ABB's IEC low-voltage motors that preceded the current M3 range (see the separately listed M3BP and M3JM ranges). The type designations, such as M2BAX 160 MLA 2, follow the scheme M2BAX <frame size> <length+variant> <pole count>.

Read on 3 more paragraphs

The register lists here 61 versions with 0.75 to 185 kW, two- to six-pole, full-load efficiencies from 82.6 to 96.3% and at 75% load from 82.5 to 96.6%. Frame sizes run from 80 to 355, all motors are recorded with the full IP55/IP56/IP65/IP66 protection combination. The combination of Finland, Poland, China and India dominates the manufacturing countries (45 of 61), with Sweden appearing singly. Testing followed the 2019 GEMS determination throughout, mostly with test method A (58); of 61 motors, 57 reach the 2005 High Efficiency Level (roughly IE2) and 3 the 2018 level (roughly IE3), only 1 stays unclassified.

As an older ABB range, M2BAX still covers a broad field of industrial applications, from pumps through fans to conveying plant, with an unusually high proportion of classified High Efficiency motors for ABB.

When buying used, what matters is bearing condition and a checked insulation resistance of the winding, the condition of shaft, key and fan cover, and a legible nameplate with frame size, mounting form and efficiency class; inverter suitability is given on most M2BAX models but should be confirmed individually from the nameplate. Spares run through the ABB service network.

Sources: Kennwerte der Modelle ABB M2BAX, ABB IEC-Niederspannungsmotoren (Hersteller)

Technical data

Engine

Rated output1.5 kWcorrect

Electrical data

Rated voltage415 Vcorrect
Number of poles4correct
Protection classIP55, IP56, IP65, IP66correct
Frame size90correct
Mounting (IEC 60034-7)B3, B5, B7, B8, B14, B34, B35, V1, V3, V5, V6, V15, V18, V19correct
Efficiency at full load85.3 %correct
Efficiency at 75 % load84.8 %correct
Efficiency at half load82.9 %correct

Origin and approval

Country of manufactureIndiacorrect

Other data

Standard appliedGreenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2019correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the ABB M2BAX 90SLA4 have?

The ABB M2BAX 90SLA4 delivers 1.5 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
