ABB M2BA355

Series: Other models

Source: https://www.abb.com/global/en/products/3AUA0000058208

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The ABB M2BA355 is a three-phase induction motor. The rated output is 132 kW. The motor is eight-pole, which at 50 Hz gives a synchronous speed of 750 rpm. The rated voltage is 415 V. The housing is frame size 355 S in foot-mounted form. The protection class is IP55. The efficiency is 95 per cent at full load, 94.9 per cent at 75 per cent load and 94.1 per cent at half load. The motor weighs 1,550 kg. At full load it delivers 1,699 Nm. Mounting arrangements to IEC 60034-7: B3, B5 and B35. The motor is built in Finland. The figures come from the Australian MEPS register under standard AS/NZS 1359.5:2000 (Legacy); measured to IEC 60034-2-1 (Edition 2.0). Rated output across the ABB range ranges from 0.75 to 185 kW; the M2BA355 sits in the upper part of that range with 132 kW. Its immediate neighbours are the M3KP315SMC6 below it with 110 kW and the M2BA 355SMA6 above it with 150 kW. 2143 ABB models across 2 series are on record. The model is listed under Electric motors. 25 verified figures from 1 source are on file.

Technical data

Engine

Rated output132 kWcorrect

Dimensions and weights

Weight1,550 kgcorrect

Electrical data

Rated voltage415 Vcorrect
Number of poles8correct
Protection classIP55correct
Frame size355 S (foot)correct
Mounting (IEC 60034-7)B3, B5, B35correct
Efficiency at full load95 %correct
Efficiency at 75 % load94.9 %correct
Efficiency at half load94.1 %correct

Origin and approval

Country of manufactureFinlandcorrect
Standard appliedAS/NZS 1359.5:2000 (Legacy)correct
Test methodIEC 60034-2-1 (Edition 2.0)correct

Frequently asked questions

How much power does the ABB M2BA355 have?

The ABB M2BA355 delivers 132 kW.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • Check the ingress rating against the installation site — outdoors or in dust the demands differ.
  • Hold the mounting form and dimensions against the existing seat before ordering.
  • The pole count sets the speed — when replacing an older unit, compare this first.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
